CASE Thermaltake View 270 TG ARGB | Mid Tower Chassis | Snow White

More Information
P/N
CA-1Y7-00M1WN-00
ซี่รี่ส์
วิว
MODEL
View 270 TG ARGB
DIMENSION (H X W X D)
456 x 230 x 454 mm
(18 x 9.1 x 17.9 inch)
NET WEIGHT
6.3 kg / 13.9 lbs.
SIDE PANEL
Tempered Glass x 2
COLOR
Black
MATERIAL
SPCC
COOLING SYSTEM
Rear(exhaust): 140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
DRIVE BAYS
2 x 3.5”, 1 x 2.5” or 2 x 2.5”
EXPANSION SLOTS
7
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
I/O PORT
USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Top:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm

Right (M/B Side):
2 x 120mm, 1 x 120mm

Rear:
1 x 120mm, 1 x 140mm

Power Cover:
3 x 120mm, 2 x 120mm, 1 x 120mm
RADIATOR SUPPORT
Top:
1 x 360mm, 1 x 240mm, 1 x 120mm

Rear:
1 x 120mm
CLEARANCE
CPU cooler max height: 180mm
VGA max length: 420mm
PSU max length: 220mm
